Intelligent programmable digital MP3 host bcp-m810
District, district broadcast function;
Power management function;
Alarm strong plug broadcast function;
Microcomputer control, single-key shuttle, graphical interface, multi-level menu operation mode;
True color TFT display, Chinese subtitles, working status at a glance;
Simplified Chinese, traditional Chinese, English three languages menu arbitrary switch;True color 3.0-inch TFT display;
Built-in 2GB memory, external expansion SD card maximum capacity up to 32G;
Support weekly calendar timing program and special date timing program to meet the needs of various times and occasions;
Support four sets of timing procedures, can be conveniently set up to multi-mode automatic operation, such as sunny mode or rainy mode;
Support computer online editing timing program, automatic power supply, broadcast partition management;
- high precision Maxim;RTC clock, timing can be accurate to seconds;
Support fire linkage function, alarm trigger signal input play specified music file;
Support external expansion power sequencer, can output short circuit signal, control peripheral equipment;
Support local fixed point call;
Support remote MIC call, and can realize fixed-point call;
Support partition, power shortcut key control, intuitive and easy to use operation;
Memory and SD card program can be played regularly, 8-channel audio output and 3-channel power output;
B powerful music playback function, support MPEG;1/2;Layer;3;, WMA, WAV, OGG, APE, FLAC and other audio formats;
Powerful media library function, users can according to their own personality needs flexible management of their music files;
Powerful sound processing function, support 3D, bass, Microsoft sound and other sound functions;
Hifi-level audio decoding performance, sound quality and professional CD comparable;
Support hd MIC recording and LINE;IN recording, FM recording;
Built-in high-definition FM radio, and support FM program recording, optional recording of selected FM radio programs;
Support remote visual remote control;
Technical parameters:
Storage mode built-in 2G memory or external SD card
Support audio formats MP3, WMA, AAC, WAV, APE, FLAC
B radio mode FM 88-108mhz
MIC 5mV, LINE 500mV
B output LINE 500mV tempered
Sound to noise ratio is greater than or equal to 85dB
Distortion degree <0.1%(1KHz)
Frequency response: 20Hz-20KHz plus or minus 3dB
Partition output 8 partition output, total capacity of 3200W.
- controlled power supply output -220V/50Hz(MAX1600W)
Fuselage size 485 x 395 x 88 mm
